Airborne Innovations introduces the NanoUXV Vehicle Computer OEM Board, which is a very compact vehicle and/or payload computer system, well suited to vehicles requiring limited size, weight, and power.
The system uses computer on modules based on the NanoETXExpress standard, currently supporting Intel Atom Z5xx and E6xx processors up to 1.6 GHz.
It contains a variety of interfaces needed by small vehicles and payloads, including dual gigabit ethernet, 3 USB2 ports, 2 RS232 ports, CAN bus, GPIO, dual analog video inputs, very wide input range power supply, 12V outputs. Expansion capability includes a MiniPCI port ideal for high power broadband radios, hardware H.264 video compressors, GPS, or other expansion modules such as Firewire. It has an Expresscard interface for high speed storage or PCIe based expansion, and a SATA port for ultra high speed storage.
It is also available with a compact and light weight enclosure with built in heat sink.
Specifications (Including Typical Z5xx CPU Module)
System
| •CPU | Intel® AtomTM Z510 / Z530 / E630T /E640T / E660T / E680T CPU Module |
| • System Chipset | Intel® System Controller Hub US15W (Z5xx) /Intel® Platform Controller Hub EG20 (E6xx) |
| • I/O Chip | Winbond W83627HG |
| • System Memory | 512MB / 1GB DDR2 SDRAM (Z5xx) orup to 2 GB DDR2-800 (E6xx) |
| • Flash Storage | 512MB / 2GB / 4GB onboard flash drive |
| • Watchdog Timer | Provided by CPU module |
I/O
| • Serial | 2x RS232 |
| • CAN Bus | Microchip MCP2515 CAN 2.0B Controller |
| • USB | 3xUSB 2.0 + 1 USB on Expresscard Connector |
| • Analog Video In | 2x Conexant Fusion 878A |
| • SATA | Supports 1.5 GBit/sec |
| • GPIO | 4 Bit digital input/output |
Display
| • Chipset | Integrated Intel® Graphics, Intel® GMA 500, HDTV/HD capable, Decoder for MPEG2(HD) / H.264 |
| • Graphics Memory | Up to 256MB |
| • Resolution | LVDS 18/24bit 1376×768@85Hz SDVO 1920×1080@50Hz (optional) |
Ethernet
| • LAN | 2x Intel® 82574L Gigabit Ethernet (Z5xx) |
Physical
| • Board Dimensions | 140 x 75mm (5.51” x 2.95” ) |
| • Weight | 120g ( 0.26 lb) |
| • Power Required | 5-36V DC |
| • Power Output | 12V @ up to 2A external, 5V + 12V internal |
Custom boards, i/o, and form factors are possible.
Please get in touch with your requirements!
